Pach and Company Slave Keypad for Quantum Series | PAC-USKP
Universal Satellite Keypad for AeGIS 9000P or Quantum Series
Features
- Satellite Keypad for all Quantum Series
- Up to 8-32 USKP can be interfaced with the models above, contact us for more detail
- Single relay
- Audible tone and LED indicator for valid and invalid access
- Independent access
- 4-Digit access code
- Tamper Proof Screws
- Brushed stainless steel, dark gray powder-coated back box
Manufacturer’s Warranty
- 24 Months
Technical Specifications
- Power Input: 12VAC 40VA or 12VDC 2 Amps
- Current Consumption: 50mA Idle, 475mA operation
- Emergency Battery: 12VDC, 4Ahr rechargeable
- Communication: RS-485 (maximum distance not to exceed 4000 ft, daisy chain connection).
- Operating Environment: 10°F to 145°F. Relative Humidity 0% to 95%.
- Relay Output: From C Dry Contact 120VAC 10A/ 24VDC 10 A/ 250VAC 7A with 5 seconds output duration.
- Mounting: Surface, Indoor or outdoor
- Construction: 16 Gauge Cold Rolled Steel with Brushed Stainless Steel Faceplate.
- Dimensions: 6-1/8”” (H) x 7-1/16“ (W), 1-1/2” (D)
- Weight: 5 lbs.
Product Literature
- Pach and Company USKP Cut Sheet
- Pach and Company USKP Manual
